YEASTAR TA1610

YEASTAR TA1610 Analog ports：16 FXO
ports Protocal: SIP and IAX2 Fax
over IP: T.38
Codec: G.711, G.722, G.723, G.726, G.729A, GSM, ADPCM The Yeastar TA1610 Supports 16 FXO ports to interface with PSTN or PABX extension port. Suitable for large-scale deployment and management, TA1610 features toll-quality voice call and top performance and reliability.TA1610 is a stand-alone FXO VoIP gateway with carrier-grade features and reliability.- 16 FXO ports- Fully compliant with SIP and IAX2- Flexible calling rules- Superb voice compression with industry standard codecs- Line echo cancellation for 8, 16, 32, 64 or 128 ms echo delays- Tested and certified with Elastix, BroadSoft, and others
Product SpecificationPorts: 16 FXO
PortsTelephony Interfaces: RJ11 and RJ21 50-pin Telco
ConnectorsNetwork Interfaces: 1 10/100BASE-T
EthernetProtocol: SIP (RFC3261),
IAX2Transport: UDP, TCP, TLS,
SRTPCodec: G.711 (alaw/ulaw), G.722, G.723, G.726, G.729A, GSM,
ADPCMVoice Capability: ITU-T G.168 LEC Echo Cancellation, Dynamic Jitter Buffer, VAD, CNG,
PLCDTMF Mode: RFC2833, SIP Info,
In-bandFax: T.30QoS: DiffServ, ToS, 802.1 P/Q
VLAN taggingNetwork: DHCP, DDNS, OpenVPN, PPPoE, Static Route,
VLANNetwork Protocol: FTP, TFTP, HTTP,
SSHManagement Protocol: TR-069*Signalling: FXO Loop Start, FXO Kewl
StartCaller ID: BELL202, ETSI (V23), NTT (V23-Japan), and DTMF-based
CIDDisconnect Methods: Busy Tone, Polarity
ReversalFXO Connectivity: Programmable AC Impedance, Hangup Detection, Answer Detection, Caller
ID DetectionPower: AC 100-240V (12V 5.5A)
